Audio Research · Foundation Series

Audio Research LS-2 Preamplifier

$8,450

Signature technologiesThe Audio Research story

On demonstration in our Portland showroom

Audio Research · Foundation Series

The LS-2 is Audio Research's pure-tube line stage: two 6H30 dual triodes in a zero-feedback Class A circuit, 12 dB of gain, balanced and single-ended in and out, with a touchscreen and optional DAC and phono cards.

Optional DAC and phono cards are available at extra cost.

2 × 6H30
tube complement
12 dB
gain, balanced and single-ended
Zero feedback
Class A
33 lb
15 kg

Authorized Audio Research dealer · Delivery and installation by Pearl Audio · Trade-ins welcome

The story

The LS-2 carries the name of the 1992 line stage that helped define the Audio Research sound, and the circuit is as direct: two 6H30 dual triodes, Class A, no negative feedback. Audio Research credits the 6H30 with the harmonic richness and tonal weight of its Reference preamplifiers, and in the LS-2 that comes with 12 dB of gain, distortion below 0.03 % at 2 V balanced and a 10 Ω balanced output impedance.

Six inputs, two of them balanced, and balanced and single-ended outputs cover a normal system. The chassis is machined aluminum, and the new touchscreen handles input naming, brightness and display color. Plug-in cards add a DAC or a phono stage without a separate box, and the Hi-Fi News review paired it with the S-200.

The LS-2 is the entry to Audio Research's tube preamplifiers and a natural partner for the D-80 or S-200. We can arrange an audition in our Portland showroom and help with loudspeaker matching, tube life and setup.

Each technology below is explained in depth in the Audio Research technology library; the Audio Research story follows the company from William Z. Johnson's first amplifier in 1949 to the Reference 330M and Reference 20.

Key technologies

  • 6H30 Class A circuit. Two dual triodes in a zero-feedback line stage.
  • Balanced and single-ended. Two XLR and four RCA inputs; both output types.
  • Touchscreen control. Input naming, brightness and color settings.
  • Optional cards. Plug-in DAC and phono cards.
  • Aluminum chassis. Shared with the LS-3, designed for stability and isolation.

Audio Research's power amplifiers of the same line, the D-80 and S-200, are its natural partners.

Finishes

  • Natural silver anodized aluminum
  • Black black anodized aluminum
Specifications
Type Tube line preamplifier
Tube complement 2 × 6H30
Gain 12 dB balanced, 12 dB single-ended
Frequency response –0.3 dB 10 Hz – 40 kHz at rated output (balanced, 100 kΩ load)
Distortion < 0.03 % THD+N at 2 V RMS balanced, 10 Hz – 80 kHz
Noise –77 dBV at maximum volume; crosstalk –76 dB
Inputs 6 (2 XLR, 4 RCA); input impedance 25 kΩ
Output impedance 10 Ω balanced
Output polarity Inverting, balanced and single-ended
Options DAC card; phono card
Power consumption 35 W max.; 4.4 W standby
Dimensions (W × H × D) 19 × 7 × 17.5 in (48.3 × 17.8 × 44.5 cm)
Weight 33 lb (15 kg); 48 lb shipping
Finishes Natural (silver) or black

Audio Research LS-2 product page and specifications

Where it sits in the range

Audio Research line preamplifiers, least to most expensive:

The D-80 is the matching tube power amplifier; the S-200 the solid-state one.

Reviews

Plan your Audio Research system with Pearl Audio

Pearl Audio is an authorized Audio Research dealer. We can arrange an audition in our Portland showroom and help with loudspeaker matching, tube life and setup. Call (503) 222-2599 or email sales@pearlaudio.com.

Signature technologies

The engineering behind the Audio Research LS-2 Preamplifier

Audio Research gives its technologies names because each one solves a specific problem. Here is what each does, where it came from, why it matters in a system, and what you may hear.

With an all-out design effort, tubes will winSince 1970

Vacuum tubes, KT150 and KT170

Audio Research has amplified with vacuum tubes since 1970 because its founder concluded that, designed without compromise, they sound better. Its output tubes have moved from the 6550 to the KT120, the KT150 in 2014 and, in the Reference 330M, the KT170, each chosen for more headroom and longer life. Read the deep diveClose

What it does

William Z. Johnson built his first commercial amplifier in 1949, tried the first transistors and found them terrible, and founded Audio Research in 1970 at a moment when the industry had decided tubes were finished; an engineer at his first trade show told him he had set audio back twenty years. His position was never dogmatic, and the company has built solid-state and hybrid products from 1976 on, but its Reference line has stayed with glass. Johnson used common, long-lived tube types, the 6550, 6L6 and 12AX7, rather than exotic ones, and that practice continues: the KT120 replaced the 6550 for more resolution and dynamics, the KT150 arrived in the GS150 and the Reference SE amplifiers of 2014 with about 3,000 hours of life, half again as long, and the Reference 330M of 2024 uses six KT170s per channel, with more plate-voltage margin and dissipation, to make 330 watts. Every current amplifier carries a tube-hour meter and individually fused output tubes.

Why it matters in a system

A tube amplifier's behavior at the edge of clipping, and the way it interacts with a loudspeaker's impedance, are what owners describe as its ease and dimensionality; Audio Research's engineering is aimed at keeping those qualities while removing the softness and noise that tubes were once excused for. Johnson's other rule was that if it measures badly it will not sound good.

What you may hear

Hi-Fi News, measuring over 400 watts from the Reference 330M: valve amps slow, lush and lazy? There goes another myth. Enjoy the Music on the I/70: it paints musical reality more accurately than anything its reviewer owned.

The working essence of every Reference preamplifierSince 1999

The 6H30 triode

Every Audio Research line stage and phono stage since the Reference 2 Mk II is built around the 6H30, a Russian nine-pin dual triode that can swing far more current than the 12AX7 and 6922 the company used for its first thirty years, run in pure class A with no feedback. Read the deep diveClose

What it does

A preamplifier tube has to drive the cable and the amplifier's input without strain, and the 6H30 does it with a reserve the older miniature triodes never had: Warren Gehl, who has evaluated every Audio Research design for about thirty years, describes it as having the most robust gain and drive capability of any nine-pin miniature tube, chosen after extended listening for current swing, dynamics and lower noise and distortion. The Reference 1 of 1996 used eight 6922s; the Reference 2 Mk II brought in six 6H30s, the Reference 3 of 2004 ran four in a zero-feedback class-A circuit, and the count has been a measure of ambition since: four in the Reference 5 and the new Reference 7, six in the Reference 6 and the Reference 20 of 2026, eight in the two-chassis Reference 10, three in the PH9 phono stage and two in the LS-2. The power supplies are regulated with a further 6H30 and a 6550.

Why it matters in a system

The line stage sets the noise floor and the dynamic reach of everything behind it, and a triode with current to spare, running in class A with no feedback, is why Audio Research preamplifiers are described in terms of depth and air rather than tube warmth. It is the single most consistent element of the company's sound since the late 1990s.

What you may hear

Michael Fremer on the six-6H30 Reference 20: a superbly balanced, exceptionally transparent, dynamically powerful, nuanced preamplifier that lets you see so far into the soundstage.

The supply is in series with the musicSince 1949

Regulated power supplies

Audio Research treats the power supply as part of the signal path, because, as Johnson put it, it is in series with the audio signal whether we like it or not. Its preamplifiers regulate their supplies electronically, often with a 6H30 and a 6550 doing the regulating, so the audio circuit sees a clean, constant voltage. Read the deep diveClose

What it does

Johnson's first amplifier had an electronically regulated supply in 1949, and the SP-10 of 1982 put the supply in its own chassis, a layout the Reference Anniversary and Reference 10 kept. In the current range the PH9 phono stage regulates its supplies with a 6550WE and a 6H30P to better than 0.01 percent line regulation; the Reference 20 of 2026 redesigned its supply with new film capacitors and reduced noise on the regulated rails by an order of magnitude; the Reference 7 uses solid-state regulation of the same platform; and the LS-3 is dual mono with separate power transformers and linear supplies. The power amplifiers store energy on the same principle: the Reference 160M holds 622 joules, and the Reference 250 of 2011 had fifty percent more capacitance than its predecessor.

Why it matters in a system

Every note an amplifier plays is drawn from its power supply, so noise and sag in the supply become noise and compression in the music. Regulation is the reason Audio Research preamplifiers have the black backgrounds and the dynamic reach that reviewers remark on, and why the company's two-chassis designs put the supply in a separate box.

What you may hear

Quiet backgrounds and dynamics that do not flatten at volume. Michael Fremer on the Reference 20: dynamically powerful, with a soundstage you can see far into.

Maple Grove, MinnesotaSince 1970

Hand-built, twice tested, auditioned

Every Audio Research product is assembled by hand in Maple Grove, Minnesota, built to order one at a time, bench-tested twice, burned in, and then listened to by the company's sonic evaluator before it ships. The output tubes are burned in for 48 hours and matched on the company's own fixtures. Read the deep diveClose

What it does

The boards are stuffed and soldered by hand; a computer-controlled soldering machine was sold because the boards it made did not sound as good. Each unit carries a production card signed by the technicians who built it, which the customer receives. Power tubes are burned in for 48 hours and matched for transconductance and plate current, and the yield is demanding: around 300 KT150s might be processed to find the 32 for a pair of Reference 750 SEs. Finished units are burned in for two days, tested on the bench twice, and then auditioned one by one in the company's listening room on Magnepan 20.7 loudspeakers by Warren Gehl, who has been chief sonic evaluator for about thirty years and approves every new design as well as every unit; if the listener does not sign off, the unit does not leave the factory. The company moved from Plymouth to a 20,000-square-foot facility in Maple Grove in August 2018, keeps a secured room of original parts going back to the early 1970s, and can restore nearly every product of the last forty-five years.

Why it matters in a system

A product that has been listened to before it is boxed is a product whose sound is known, and an amplifier that can be serviced for decades is one worth buying for decades. Johnson's rule was that the product should be serviceable or capable of being returned to a serviceable condition.

What you may hear

Consistency between the review sample and the one in your rack, and a reason that forty-year-old Audio Research preamplifiers are still in use.

All Audio Research technologies and the company story

The Audio Research story

High Definition since 1970: American tube amplification, balanced and class A, hand-built and listened to in Minnesota.

Founded 1970 in Minneapolis, Minnesota; built by hand in Maple Grove, Minnesota since 2018 by William Z. Johnson · audioresearch.com

Milestones

  1. 1949 The first amplifier William Z. Johnson builds a three-chassis, all-triode, transformer-coupled amplifier with a regulated power supply for a customer with a Klipschorn. In 1951 he founds Electronic Industries in Minneapolis.
  2. 1970 Audio Research founded Free of Peploe, the company that had bought Electronic Industries in 1968, Johnson starts Audio Research in Minneapolis and shows the Dual 50, SP-1 and SP-2. An engineer tells him he has set audio back twenty years.
  3. 1972 SP-3 Eight 12AX7s and $595. J. Gordon Holt finds it modifies the signal less than any other preamplifier available; The Absolute Sound later calls it the most important debut of the high-end era. High Definition becomes the company's trademark.
  4. 1979 D-79 The High Definition Power Amplifier D-79: nineteen tubes, ninety pounds, after the D-75, D-76 and the 150-watt Dual 150 of 1975. The SP-6 preamplifier had arrived in 1978.
  5. 1985 SP-11 After the two-chassis SP-10 of 1982, the hybrid SP-11 puts a triode and a FET in every stage. Harry Pearson calls it the world's best preamplifier; about three thousand are built.
  6. 1995 The Reference series The Reference 1 line stage and Reference 600 monoblocks begin the flagship line. The Reference 2 Mk II introduces the 6H30 triode; the fully balanced Reference 3 follows in 2004.Audio Research Reference 20 Preamplifier
  7. 2008 Quadrivio and Fine Sounds Johnson, 81, sells to the Italian group that owns Sonus faber; it adds Sumiko, Wadia and McIntosh and becomes the McIntosh Group in 2016. The Reference 5 and Reference Phono 2 arrive in 2009.
  8. 2010 Reference Anniversary A two-chassis preamplifier for the fortieth year. In 2011 the Reference 250 and 750 amplifiers bring the KT120 tube; William Z. Johnson dies on December 10, 2011, at 85.
  9. 2014 The G Series and the KT150 Handles gone, a restyled look, and the KT150 output tube, which goes into the Reference 75SE, 150SE and 250SE with about 3,000 hours of life.
  10. 2017 Foundation series and auto-bias The LS28, PH9 and DAC9, styled by Livio Cucuzza; the VT80 carries the company's first auto-bias circuit.Audio Research PH9 Phono Stage
  11. 2018 Reference 160M; Maple Grove Auto-bias comes to the Reference line with the GhostMeter faceplate and 110 kHz transformers; the company moves to Maple Grove, Minnesota in August. The Reference 160S follows in 2019.Audio Research REF160M MkII Amplifier
  12. 2020 Fifty years; sold to Trent Suggs The Reference 6SE and Phono 3SE, Ken Kessler's Making the Music Glow, and in August a sale by the McIntosh Group to the company's former sales manager. The I/50 arrives in 2021.
  13. 2023 AR Tube Audio Corporation After an assignment for the benefit of creditors in April, the company is sold in June to a new corporation led by Valerio Cora of Acora Acoustics, staff intact. The Reference 160M MkII had arrived in March.
  14. 2024 Reference 330M Six KT170s a side, 330 watts, debuted at Munich: in the company's words the finest amplifier it has created.Audio Research Reference 330M Monoblock Power Amplifiers (pair)
  15. 2025 Six core products The I/70 integrated, LS-2 and LS-3 line stages, S-100 and S-200 solid-state amplifiers and the D-80: the largest introduction in the company's history. The I/55 succeeds the I/50.Audio Research I/70 Integrated Amplifier
  16. 2026 Reference 20, Reference 7 and 80X At AXPONA in April, the first new flagship line stage since 2012 wins hi-fi+'s best debut of the show. In July the company's leadership changes; operations and service continue independently in Maple Grove.Audio Research Reference 7 Preamplifier
Read the Audio Research story
Audio Research VT80SE tube amplifier in the Small Room

William Zane Johnson learned electronics in the military, opened a radio and television repair shop in Minneapolis, and in 1949 built his first commercial amplifier for a customer with a Klipschorn: three chassis, all triodes, transformer-coupled, with a separate electronically regulated power supply. In 1951 he founded Electronic Industries, a repair shop, hi-fi retailer and custom amplifier builder, and spent the 1950s and 1960s improving on the Dynaco designs of the day one amplifier at a time, convinced that power supplies and transformers deserved more care than the industry gave them. He tried the first transistors and found them, in his word, horrendous. In 1968 he sold the business, his patents and his files to Peploe, Inc. and became its director of research; in 1970, as he put it, he obtained his freedom from that company and started Audio Research.

He showed the Dual 50 amplifier and the SP-1 and SP-2 preamplifiers at a trade show in Washington in 1970, and an engineer told him he had set the audio industry back twenty years. Two years later the SP-3, eight 12AX7s run at reduced heater voltage and $595, was reviewed by J. Gordon Holt in Stereophile as modifying the input signal less than any other preamplifier available, and The Absolute Sound later called it the single most important debut of the high-end era. Audio Research trademarked the phrase High Definition and has kept it as a guiding principle since. The D-75 and D-76 amplifiers, the 150-watt Dual 150 of 1975, the SP-6 of 1978 and the nineteen-tube D-79 of 1979 followed; the SP-10 of 1982 put the power supply in a second chassis, and the hybrid SP-11 of October 1985, a triode and a FET in every stage, was called the world's best preamplifier by Harry Pearson and sold about three thousand units.

The Reference series began in 1995 and 1996 with the Reference 1 line stage and the Reference 600 monoblocks, and the Reference 2 Mk II brought in the 6H30 triode that has been the heart of every Audio Research preamplifier since. The Reference 3 of 2004 was fully balanced, class A and feedback-free; the Reference 5 and Reference Phono 2 arrived in 2009, the two-chassis Reference Anniversary in 2010 for the fortieth year, and the Reference 250 and 750 amplifiers in 2011 with the KT120 tube. In 2008 Johnson, then 81, sold the company to Quadrivio, the Italian group that had bought Sonus faber the year before and would add Sumiko, Wadia and McIntosh to form Fine Sounds, later the McIntosh Group. He died on December 10, 2011, at 85.

Under the group the company's look changed and its engineering continued. The G Series of 2014 removed the handles and brought the KT150 tube, which went into the Reference SE amplifiers the same year; the Reference 6 followed in 2015, the Foundation series of 2017, the LS28, PH9 and DAC9, was styled by Livio Cucuzza, and the VT80 introduced the company's first auto-bias circuit. The Reference 160M of 2018, with auto-bias, the GhostMeter faceplate and transformers reaching 110 kHz, was described by its designer as the apex of the Audio Research design language; the Reference 160S came in 2019. In August 2018 the company moved from Plymouth to a 20,000-square-foot facility in Maple Grove, Minnesota, where it still is. For the fiftieth anniversary in 2020 came the Reference 6SE, the Reference Phono 3SE, Ken Kessler's history Making the Music Glow, and, in August, a sale: the McIntosh Group sold Audio Research to Trent Suggs, its former North American sales manager, who said he had no bank note, no debt and no partners. The I/50 of 2021, in six colors, was built to bring a new generation to the brand.

The independence was short. In April 2023 the company entered an assignment for the benefit of creditors in Minnesota, and on June 20 a judge approved its sale to a new corporation, AR Tube Audio, led by Valerio Cora of Acora Acoustics, with the staff kept on; the difficulties, Michael Fremer reported, were not caused by poor sales or waning interest. What followed was the largest burst of new products in the company's history. The Reference 330M monoblocks, six KT170s a side for 330 watts, debuted at Munich in May 2024 from a team of newly hired engineers; six core products, the I/70, LS-2, LS-3, S-100, S-200 and D-80, arrived in 2025; and at AXPONA in April 2026 the Reference 20 preamplifier, the first new flagship line stage since 2012, the Reference 7 and the Reference 80X were premiered, the Reference 20 winning hi-fi+'s award for the best debut of the show. In July 2026 Cora stepped back from day-to-day leadership, with the company's financial backer providing oversight and two general managers running Maple Grove; Audio Research's operations, development, dealer support and service continue independently.

Fifty-six years on, the method is Johnson's. Every product is built by hand to order, tested twice, burned in, and listened to by Warren Gehl, the company's sonic evaluator for about thirty years, before it ships; the output tubes are burned in and matched on the company's own fixtures; nearly everything built since the 1970s can still be restored from a secured room of original parts. The tubes are common, long-lived types, the circuits are balanced and class A, the power supplies are regulated, and the transformers are the company's own. Johnson's test was that if it measures badly it is not going to sound good, and his bet was that with an all-out design effort vacuum tubes would win. The Reference 330M and Reference 20 are the current evidence.

The complete Audio Research story and technology library
