Pass Labs · X Series
$16,390
Pass Labs · X Series
The most powerful stereo amplifier Pass Labs makes: 350 watts per channel from 72 output MOSFETs per channel in the 11-inch-tall .8 chassis.
Weighs 127 lb; plan for an amplifier stand or floor placement.
Authorized Pass Labs dealer · Delivery and installation by Pearl Audio · Trade-ins welcome
The story
The X350.8 is the largest and most powerful stereo amplifier in the Pass Labs line. It carries 72 power MOSFETs per channel, the same complement as the X600.8 and XA200.8 monos, in the 11-inch-tall .8 chassis, and is rated at 350 W per channel into 8 Ω with a damping factor of 150. The supply draws 600 W at idle. As with the other Class AB .8 amplifiers, a substantial Class A bias handles the first watts before the output stage moves into AB.
Positive Feedback's Pete Davey, returning to the X350.8 after months with Class D amplifiers, found more bass grip, dynamic control and midrange texture with his ribbon loudspeakers, at the cost of heat and efficiency; the magazine had given the X350.8 a Writers' Choice award in 2016. Pass positions it for listeners who want the ease of its sound with extra reserve: more slam, control and headroom without a hard or mechanical presentation.
The X350.8 is the stereo amplifier for large rooms and loudspeakers that benefit from firm control. The XP-22 or XP-32 partner it. For the same device count in mono form, the X600.8 delivers 600 W per channel.
Silver is the standard finish shown. Black is available to order at additional cost; ask us for a quote.
| Type | Stereo power amplifier |
| Class of operation | Class AB, with Class A bias at low output |
| Power output (8 Ω) | 350 W per channel |
| Power output (4 Ω) | Not published by Pass Labs |
| Gain | 26 dB |
| Input for full power (26 dB gain) | 2.65 V |
| Frequency response | 1.5 Hz – 100 kHz (Pass Labs spec) |
| Input impedance | 50 kΩ single-ended; 100 kΩ balanced |
| Damping factor | 150 |
| Output devices | 72 per channel |
| Inputs | Balanced XLR and single-ended RCA |
| Outputs | Speaker binding posts |
| Power consumption at idle | 600 W |
| Standby power | Less than 1 W |
| Dimensions (W × D × H) | 19 × 21.5 × 11 in |
| Weight | 127 lb |
| Sold as | Single stereo amplifier |
The largest Pass Labs stereo amplifier.
