Pass Labs · XP Series
$6,710
Not currently in our rooms. For a serious buyer we will often bring a piece in from the manufacturer for a private session — tell us about your system and what you are weighing it against, and we will advise.
Pass Labs · XP Series
Wayne Colburn's single-chassis line preamplifier: the Xs Preamp's single-stage volume control, a shielded toroidal supply and five inputs, with a remote.
Single chassis. Five inputs, two outputs, balanced and single-ended. Remote supplied.
Authorized Pass Labs dealer · Delivery and installation by Pearl Audio · Trade-ins welcome
The story
The XP-12 is the entry to the Pass Labs line preamplifiers, and it borrows from the top. Its volume control is the single-stage attenuator developed for the Xs Preamp, read by a microcontroller from an optical encoder, with 100 steps of about 1 dB over a range greater than 90 dB; because it is an attenuator the signal passes at full level only at the top of its range. Gain comes from high-bias Toshiba transistors and an auto-bias output stage. The toroidal power supply is new to the XP-12, with electrostatic and Mu-metal shielding, vacuum impregnation and epoxy fill, followed by multi-stage filtering.
Pass specifies a response within ±0.05 dB from 10 Hz to 20 kHz, an output impedance of 25 Ω single-ended and 50 Ω balanced, crosstalk better than 100 dB and 9.3 dB of balanced gain. Five inputs and two outputs are both balanced and single-ended. The Absolute Sound gave the XP-12 a Golden Ear award in 2021 and an Editors' Choice in 2022, and reviewing it with the XA25 described a warm, rich, musically engaging pair. Future Audiophile called it the ultimate expression of trickle-down technology; Positive Feedback's Juan C. Ayllon uses it as his reference.
The XP-12 is the preamplifier for a single-chassis Pass system with the XA25, XA30.8 or X150.8, with the XP-17 as its phono partner. The two-chassis XP-22 separates the supply and adds a larger, higher-biased output stage.
Silver is the standard finish shown. Black is available to order at additional cost; ask us for a quote.
| Type | Line preamplifier, single chassis |
| Gain | 9.3 dB balanced |
| Inputs / outputs | 5 inputs, 2 outputs; balanced XLR and single-ended RCA |
| Volume control | Single-stage attenuator, 100 steps of about 1 dB; remote supplied |
| Frequency response | ±0.05 dB, 10 Hz – 20 kHz |
| Input impedance | 22 kΩ |
| Output impedance | 25 Ω RCA; 50 Ω XLR |
| Crosstalk | Better than 100 dB |
| Distortion | Less than 0.001% at 1 V, 1 kHz |
| Power consumption | 30 W |
| Dimensions (W × D × H) | 17 × 12 × 4 in |
| Weight | 20 lb |
The single-chassis Pass Labs line preamplifier.
The matching phono preamplifier is the Pass Labs XP-17.
